P6100 100MHz Oscilloscope Probe Price in Bangladesh

The P6100 100MHz Oscilloscope Probe is a general-purpose passive probe designed for measuring electrical signals with an oscilloscope. It provides a convenient 1X/10X selectable attenuation function, allowing the user to choose an appropriate measurement mode for different signal conditions.

In the commonly specified P6100 design, the probe provides up to 100MHz bandwidth in 10X mode, with an input resistance of approximately 10MΩ. The 10X setting reduces the loading effect on the circuit and is particularly useful when measuring faster or higher-frequency signals.

The probe also includes an adjustable compensation function. Proper compensation helps the probe work correctly with the oscilloscope’s input characteristics and allows waveforms to be displayed more accurately.

With a flexible cable of approximately 120cm, the P6100 is convenient for electronics laboratories, educational workbenches, circuit troubleshooting and general signal measurement.

What Is an Oscilloscope Probe?

An oscilloscope probe is an accessory that connects a circuit under test to an oscilloscope. It transfers the electrical signal from a test point to the oscilloscope input so that voltage changes can be displayed as a waveform.

A good probe should introduce as little unwanted loading and signal distortion as practical. The P6100 addresses this through selectable attenuation and relatively low input capacitance in its 10X mode.

Key Features

• Up to 100MHz bandwidth
• Switchable 1X / 10X attenuation
• Approximately 10MΩ input resistance in 10X mode
• Adjustable probe compensation
• Fast response with rise time below approximately 3.5ns
• Standard BNC connection
• Approximately 120cm flexible cable
• Removable hook-style test tip on common versions
• Ground lead for circuit reference
• Compact and lightweight design
• Suitable for many general-purpose oscilloscopes
• Useful for analog and digital signal measurements

Technical Specifications

Specifications can vary by manufacturer and P6100 revision. For example, some P6100 datasheets specify slightly different capacitance or voltage figures, so the exact supplied version should be checked before precision or high-voltage measurement.

1X vs 10X Mode

The P6100 provides two attenuation settings.

1X Mode

In 1X mode, the signal is passed with little attenuation, which can be useful for relatively low-frequency and low-level signals. However, the higher input capacitance can place more loading on the circuit.

10X Mode

In 10X mode, the input signal is attenuated by a factor of ten before reaching the oscilloscope. This provides higher input resistance and lower capacitance, reducing circuit loading and allowing the probe to support its full specified bandwidth on common P6100 versions.

Working Principle

The P6100 is a passive oscilloscope probe. Its attenuation network and compensation circuitry are designed to transfer the measured signal to the oscilloscope while controlling the probe’s effect on the circuit.

When the probe is set to 10X, the attenuation network reduces the signal amplitude by approximately ten times while increasing the effective input resistance to around 10MΩ.

The adjustable compensation capacitor allows the probe to be matched to the oscilloscope input. Correct compensation is important because an improperly compensated probe can alter the displayed shape of a waveform.

Applications

The P6100 100MHz Oscilloscope Probe can be used for:

• Analog waveform measurement
• Digital signal testing
• Oscillator circuit testing
• Microcontroller signal analysis
• PWM waveform observation
• Power-supply signal analysis
• Audio and low-frequency electronics testing
• Circuit troubleshooting
• Electronics laboratory experiments
• Educational electronics projects
• PCB debugging
• General oscilloscope measurements

Advantages

100MHz Bandwidth

The P6100 provides up to 100MHz bandwidth in its 10X configuration, making it suitable for a broad range of general-purpose electronics measurements.

Selectable Attenuation

The 1X/10X switch provides flexibility for different measurement requirements.

High Input Resistance

The 10X mode provides approximately 10MΩ input resistance, helping reduce loading on the circuit being measured.

Adjustable Compensation

The compensation adjustment allows the probe response to be matched appropriately to the oscilloscope input.

Flexible Cable

The approximately 120cm cable provides convenient reach around an electronics workbench.

Limitations

• The actual bandwidth depends on the selected attenuation mode and oscilloscope.
• Different P6100 versions may have different electrical specifications.
• Probe compensation should be properly adjusted for accurate waveform reproduction.
• The probe is not intended to replace specialized differential or isolated probes.
• The voltage rating must never be exceeded.
• High-voltage measurements require appropriate equipment, training and safety procedures.

Usage Tips

• Check the probe’s attenuation setting before taking measurements.
• Match the oscilloscope’s channel attenuation setting with the probe setting.
• Use the 10X mode when its higher input impedance and lower capacitance are beneficial.
• Properly compensate the probe before making precision waveform measurements.
• Keep the ground connection short when measuring faster signals to reduce unwanted noise and ringing.
• Inspect the probe cable, insulation, connector and test tip before use.
• Always stay within the probe and oscilloscope voltage ratings.
• For high-voltage circuits, use only equipment specifically rated for the measurement and follow appropriate electrical safety procedures.

Why Choose P6100 100MHz Oscilloscope Probe?

The P6100 is a practical general-purpose probe for electronics students, hobbyists, technicians and engineers who need a reliable connection between a circuit and an oscilloscope.

Its combination of 100MHz bandwidth, 1X/10X attenuation, adjustable compensation, high input resistance and flexible cable makes it suitable for many everyday signal-measurement tasks.

Why Buy from ElectroXBD?

ElectroXBD offers a range of electronic components, measurement equipment, development boards, tools and accessories for electronics enthusiasts, students, technicians and engineers in Bangladesh.

The P6100 100MHz Oscilloscope Probe is a useful accessory for anyone working with compatible oscilloscopes and requiring a versatile probe for waveform measurement and circuit troubleshooting.

Frequently Asked Questions (FAQ)

1. What is the bandwidth of the P6100 probe?

The commonly specified P6100 provides up to 100MHz bandwidth in 10X mode. In 1X mode, the bandwidth is typically around 6MHz.

2. Does the P6100 support both 1X and 10X?

Yes. The probe has a selectable 1X/10X attenuation function.

3. What is the input resistance in 10X mode?

The commonly specified input resistance is approximately 10MΩ in 10X mode and 1MΩ in 1X mode.

4. Does the P6100 require compensation?

Yes. The probe has an adjustable compensation range, commonly around 10–30pF depending on the version. Proper compensation helps improve waveform accuracy.

5. How long is the P6100 cable?

Common P6100 versions use a cable approximately 120cm long.

6. Is P6100 compatible with standard oscilloscopes?

P6100 probes commonly use a standard BNC connection and are designed for use with many general-purpose oscilloscopes. However, users should verify connector and electrical compatibility with their specific oscilloscope.

7. What is the maximum voltage rating?

A commonly specified P6100 version is rated below 200V DC + AC peak in 1X mode and below 600V DC + AC peak in 10X mode. Ratings vary by manufacturer/version, so the markings and datasheet of the actual probe should always be followed.

8. What is included with the P6100?

A typical package contains one P6100 oscilloscope probe, with common versions also supplied with a ground lead, hook/test accessories and a compensation adjustment tool.
