CD74HC4067 16 Channel Analog Multiplexer Price in Bangladesh

The CD74HC4067 16 Channel Analog Multiplexer is a versatile CMOS-based analog switch designed to expand the input and output capabilities of microcontrollers such as Arduino, ESP32, ESP8266, STM32, Raspberry Pi (with ADC), and other embedded development platforms. It allows a single analog or digital input/output pin to communicate with 16 separate channels, making it an excellent solution for projects requiring multiple sensors or signal sources while using very few GPIO pins.

Modern embedded systems often face limitations in the number of available analog input pins. For example, Arduino Uno provides only six analog inputs, while many applications require monitoring numerous sensors simultaneously. The CD74HC4067 solves this limitation by functioning as a 16-to-1 analog multiplexer, enabling one common signal pin to be connected to any one of sixteen independent channels under the control of only four digital address lines.

The device supports both analog and digital signals, making it suitable for reading analog sensors, controlling digital switches, routing communication signals, selecting audio channels, multiplexing voltage measurements, and numerous other switching applications. It features low ON resistance, high switching speed, break-before-make switching, and low power consumption, ensuring reliable signal transmission with minimal distortion.

The module uses four selection pins (S0, S1, S2, and S3) to choose one of the sixteen available channels. An additional Enable (EN) pin allows users to disconnect all channels when required. This simple addressing method makes software implementation straightforward while significantly reducing the number of microcontroller pins needed.

The CD74HC4067 is widely used in robotics, IoT systems, automation, environmental monitoring, sensor networks, laboratory instruments, industrial data acquisition, and educational electronics projects. It is particularly useful when multiple analog sensors such as LDRs, potentiometers, pH sensors, gas sensors, moisture sensors, and temperature sensors need to be connected to a single ADC input.

In addition to sensor expansion, the module is also employed in audio routing, communication signal switching, measurement systems, multiplexed keyboards, touch sensing applications, battery monitoring systems, and signal acquisition devices. Because it supports bidirectional analog switching, the module can function as either a multiplexer or a demultiplexer depending on the application.

With its compact PCB design, low power consumption, and excellent compatibility with popular development boards, the CD74HC4067 has become one of the most widely used expansion modules in the maker and embedded systems community.

🔍 What is a 16 Channel Analog Multiplexer?

A 16 channel analog multiplexer is an electronic switching device that connects one common signal line to one of sixteen input/output channels.

Instead of requiring sixteen separate analog input pins, a microcontroller can read sixteen sensors using only:

• Four address pins (S0–S3)
• One signal pin
• One optional Enable pin

This significantly expands the number of sensors or signals that can be connected without increasing hardware complexity.

✨ Key Features of CD74HC4067 16 Channel Analog Multiplexer

• 16 independent analog/digital channels
• Single common signal pin
• Four digital address selection pins
• Enable control pin
• Supports analog and digital signals
• Low ON resistance
• High-speed CMOS switching
• Break-before-make switching
• Low power consumption
• Wide operating voltage range
• Bidirectional signal switching
• Compact breakout module
• Easy Arduino library support
• Compatible with ESP32 and STM32
• Ideal for sensor expansion
• Suitable for robotics and IoT projects

⚙️ Technical Specifications

• IC Model: CD74HC4067
• Function: 16 Channel Analog Multiplexer/Demultiplexer
• Multiplexer Configuration: 16:1
• Operating Voltage: 2V–6V
• Logic Voltage: 3.3V / 5V Compatible
• Control Inputs: S0, S1, S2, S3
• Enable Pin: Yes
• Common Signal Pin: SIG
• Number of Channels: 16
• Typical ON Resistance: 60–70Ω
• Bandwidth: Approximately 89MHz
• Operating Temperature: -55°C to +125°C (IC specification)
• Signal Type: Analog and Digital
• Applications: Sensor Expansion, Signal Routing, Data Acquisition, Arduino Projects

⚡ Working Principle of CD74HC4067 16 Channel Analog Multiplexer

The CD74HC4067 operates as an electronically controlled switch.

Using four digital selection inputs (S0–S3), the microcontroller selects one of the sixteen available channels. Once selected, that channel is electrically connected to the common SIG pin, allowing the microcontroller to read or transmit the signal.

For example, if sixteen potentiometers are connected to channels C0–C15, the Arduino simply changes the address pins to select each channel one at a time and reads the analog voltage through a single analog input pin.

The built-in break-before-make feature ensures that one channel disconnects before another connects, reducing switching errors and preventing short circuits between channels.

🔧 Applications of CD74HC4067 16 Channel Analog Multiplexer

• Arduino analog input expansion
• ESP32 sensor expansion
• Raspberry Pi ADC projects
• Multiple potentiometer reading
• LDR sensor arrays
• Gas sensor monitoring
• Soil moisture sensor systems
• pH monitoring systems
• Temperature sensor networks
• Robotics projects
• IoT data acquisition
• Audio signal switching
• Battery voltage monitoring
• Communication signal routing
• Laboratory instruments
• Industrial automation

✅ Advantages of CD74HC4067 16 Channel Analog Multiplexer

• Expands analog input capacity
• Supports both analog and digital signals
• Requires very few GPIO pins
• High-speed signal switching
• Low power consumption
• Compact PCB design
• Easy software control
• Wide operating voltage
• Excellent Arduino compatibility
• Cost-effective solution

⚠️ Limitations

• Only one channel can be active at a time.
• Not suitable for simultaneous sampling of multiple signals.
• Small switching resistance may slightly affect high-precision analog measurements.
• High-speed analog applications may require proper PCB layout and filtering.

🛠️ Installation / Usage Tips

• Connect VCC to 3.3V or 5V according to your microcontroller.
• Connect the SIG pin to the analog or digital I/O pin.
• Use S0–S3 to select the desired channel.
• Keep analog signal wires as short as possible.
• Add a short delay after switching channels before reading analog values for improved accuracy.
• Use decoupling capacitors near the power pins.
• Keep unused inputs disconnected or properly terminated if necessary.
• Verify wiring before powering the circuit.

💡 Why Choose CD74HC4067 16 Channel Analog Multiplexer

The CD74HC4067 is one of the most popular multiplexer ICs for embedded electronics because it provides a simple, reliable, and inexpensive method of expanding analog and digital input channels. Its compatibility with Arduino, ESP32, Raspberry Pi, and many other platforms makes it an essential module for makers, students, researchers, and engineers.

Whether you’re building a sensor network, robotics system, environmental monitoring station, or IoT project, this module provides an efficient way to connect multiple devices while conserving valuable microcontroller pins.

🛒 Why Buy from Electroxbd

• 100% Quality Tested Products
• Trusted Source for Reliable Electronic Parts
• Fast Delivery Across Bangladesh
• Competitive Pricing
• Genuine Arduino Compatible Modules
• Dedicated Technical Support
• Perfect for Students, Engineers, Researchers, and Makers

❓ Frequently Asked Questions (FAQ)

What is the CD74HC4067 16 Channel Analog Multiplexer used for?

It is used to expand the analog or digital input/output capability of microcontrollers by allowing one signal pin to connect to any of 16 channels.

Can the CD74HC4067 work with Arduino?

Yes, it is fully compatible with Arduino Uno, Nano, Mega, ESP32, ESP8266, STM32, and other popular development boards.

Can this module switch both analog and digital signals?

Yes, the CD74HC4067 supports bidirectional switching for both analog and digital signals.

How many GPIO pins are required to control this module?

Typically, four address pins (S0–S3), one signal pin, and optionally one Enable pin are used to control all 16 channels.

Where can I buy the CD74HC4067 16 Channel Analog Multiplexer in Bangladesh?

You can buy the CD74HC4067 16 Channel Analog Multiplexer from Electroxbd, a trusted electronics components supplier in Bangladesh.

Common Questions:

Q: What is the price of CD74HC4067 16 Channel Analog Multiplexer in Bangladesh?

A: The latest price of CD74HC4067 16 Channel Analog Multiplexer in Bangladesh is 250 BDT.

Q: Where to buy CD74HC4067 16 Channel Analog Multiplexer in Bangladesh?

A: You can buy the CD74HC4067 16 Channel Analog Multiplexer at the best price from ElectroXBD in Bangladesh.
